The MQ-2 gas sensor uses tin dioxide (SnO2), a gas-sensitive material with low conductivity in clean air. When combustible gases are present in the sensor's environment, the sensor's conductivity increases with the concentration of those gases in the air.
A simple circuit can convert this change in conductivity into an output signal corresponding to the gas concentration. The MQ-2 gas sensor is highly sensitive to liquefied petroleum gas (LPG), propane, and hydrogen, and is also ideal for detecting natural gas and other combustible vapors. This sensor can detect a variety of combustible gases and is a low-cost sensor suitable for a wide range of applications.
Input voltage: DC5V Power consumption (current): 150mA
DO output: TTL digital 0 and 1 (0.1V and 5V)
AO output: 0.1-0.3V (relatively pollution-free), maximum concentration voltage around 4V
Special reminder: After the sensor is powered on, it needs to warm up for about 20 seconds for the measured data to stabilize. Sensor heating is normal because it contains an internal heating element; however, if it becomes too hot to touch, it is abnormal.
Wiring method:
1. VCC: Connect to the positive terminal of the power supply (5V)
2. GND: Connect to the negative terminal of the power supply
3. DO: TTL switch signal output
4. AO: Analog signal output
It can be used as a gas leak monitoring device in homes and factories, and is suitable for detecting liquefied gas, butane, propane, methane, smoke, etc.
Detection concentration: 300-10000ppm (combustible gas)
Heating resistance: 31Ω ± 32Ω (room temperature)
Heating power consumption: ≤900mW
Sensitive element surface resistance: 2KΩ 2-20KΩ (in 2000ppm C3H8)
Sensitivity: Rs(in air)/Rs(1000ppm isoalkane) ≥ 5
Concentration slope: ≤0.6 (R 3000ppm/R 1000ppm C3H8)
Temperature and humidity: 20℃ ± 2℃; 65% ± 5%RH
Preheating time: For first-time use or after a long period of non-power-on, at least 48 hours are required. For daily use, a 2-5 minute warm-up is usually sufficient to reach a stable operating state after powering on.
